Specifications
| Mechanical barrel length | 160mm |
| magnification | 40X-1600X |
| Stage size | Mobile platform: 140 × 140mm; moving range: 75 × 50mm, cursor: 0.1mm |
| pupil distance | 55-75 mm |
| Focusing device | 30 mm coarse fretting coaxial focusing mechanism with limit, coarse focusing tension adjustment device, fine-tuning grid value 0.002mm |
| condenser | N.A.1.25 Adjustable medium Abbe condenser with variable light bar |
| Color filter | Blue, yellow, green |
| Light source | Halogen lamp 6V/20W, Kohler lighting, adjustable luminance |
| Computer imagery system | (1) Digital CMOS camera, 5 million pixels, with geometric measurement analysis software, the software for point, line, circle and arc, straightness, roundness, area and other measurements; (2) MCL-Z adapter mirror; (3) computer self-purchased |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/44944/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
