Specifications
| magnification | 7.5x-135x |
| Zoom Ratio | 1:18 |
| Magnification Range | 7.5x-135x |
| Focusing device | Manual focusing device with built-in CounterWeight and focusing mechanism Shaft thick, fine-tuning knob (60 + 90mm) |
| Binocular pupil distance adjustment range | 52-76mm |
| diopter compensation | Vision correction range + 5~ -5 |
| Color temperature compensation | Color temperature automatic compensation |
| Light source | LED Cold Light source; Built-in OCC; Illuminator: OCC oblique light illumination, illumination area: diameter 60mm; built-in aperture diaphragm |
| Computer imagery system | (1) Digital CMOS camera, 12 million pixels. With geometric measurement analysis software, the software for point, line, circle and arc, straightness, roundness, area and other measurements; (2) MCL-Z adapter mirror; (3) computer self-purchased |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/44952/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
