IPRE H16 infrared thermal imagery instrument, temperature measurement -20 ℃~ 400 ℃

Temperature range -20 ℃~ 400 ℃, accuracy +/- 2 ℃ or +/- 2%, Detector resolution 160 x 120, Response band 8-14 μm.
Model：
Certificate
Contact
Details SPEC

Ipre H16 Infrared thermal imagerySPEC

Ipre H16 Infrared thermal imageryDetails

Ipre H16 Infrared thermal imageryPacking list

SKU
NB045097
Product model
H16
Detector type
Uncooled Detector
Detector resolution
160 x 120
Response band
8-14μm
IFOV
2.74mrad
NETD (Noise Equivalent Temperature Difference)
<50mk(@25″ C.F#=1.0)
Minimum measurement distance
0.2m
Field of view
25°x19°
aperture
F1.1
Numerical zoom
1X、2X、4X
Accuracy
+/- 2 ″ C or +/- 2%, MAX Maximum
Temperature Measurement Range
-20℃~400℃
Maximum image size
800W
Picture resolution
1600 x 1200
Video resolution
1600 x 1200
frame rate
25Hz
display
3.5 ″ LCD capacitive touch screen 640 * 480
image mode
Support 7 pseudo-color modes such as white hot and iron red
screen display mode
Visible light, thermal imagery, dual light fusion, picture-in-picture
Laser pointer
support
storage
16G
take a picture
Visible light, thermal imagery, dual light fusion, picture-in-picture
video recording
Visible light, thermal imagery, dual light fusion, picture-in-picture
Heiming
support
WIFI
support
Text annotation
support
phonetic annotation
Support (60S)
interface language
Chinese/English
Battery type
Li-ion battery
Working time of battery
5h, can be replaced on site, can be charged
Hardware Interface
TYPE-C
Operating temperature
-10℃~-50℃
fall
2m
Protection level
IP54
Dimension
244 mm x 100 mm x 104 mm
Weight
660g
H16
Infrared thermal imagery
Temperature range -20 ℃~ 400 ℃, accuracy +/- 2 ℃ or +/- 2%, Detector resolution 160 x 120, Response band 8-14 μm.
IPRE H16 infrared thermal imagery instrument, temperature measurement -20 ℃~ 400 ℃ Picture

null

FAQ
QIs the price listed on the website the final cost for overseas purchases?
ANo, it isn't. This is the ex-factory price of the product in the Chinese Mainland. In addition to this price, buyers from different countries need to account for additional costs such as shipping fees, tariffs, and others. For specific regional quotes, please consult our customer service or fill out a quotation form.
QWhat is the specific process for purchasing the product?
AFirst, please click on the quotation form on the website and fill in detailed information. Our customer service personnel will then send you a quotation based on your specific country and region, confirming payment and delivery methods. Following this, we proceed with contract signing, payment, and shipment. You can then await delivery.
QWhat should I do if the instrument I purchase needs repair?
AAfter-sales repair for overseas instruments is an unavoidable issue. Our repair terms stipulate that the sender is responsible for the shipping and insurance costs incurred for the repair. Repairs within the warranty period are free, while repair costs beyond the warranty period are determined based on the actual situation.
