Defelsko PosiTector 6000 FNS3 Coating Thickness Gauge metal substrate Automatic substrate type identification and measurement

SE
Advanced Coating Thickness Gauge, magnetic and nonmagnetic dual function thickness measurement, range 0~1500μm, error +/- 1%, color touch screen, screen image saving 100, replaceable split probe, supporting PosiSoft software suite.
$1882.00/set
PromotionLoading...
Coupon
Certificate
Contact
Details SPEC Con VIDEO CAT OI
Similar products

Defelsko PosiTector 6000 FNS3 Coating Thickness GaugeSPEC

Defelsko PosiTector 6000 FNS3 Coating Thickness GaugeDetails

Defelsko PosiTector 6000 FNS3 Coating Thickness GaugePacking list

SKU
NB000451
Measurement principle
Magnetic Induction + eddy Current
Measurement range
0~1500μm
margin of error
±1%
Resolution
0.1μm
probe
FNS3 Probe (Universal)
statistical function
Measurement times, MAX Maximum, MIN Minimum, Average, Standard deviation
icon function
Yes.
Power Supply
3 * AAA alkaline battery
Standards
ISO 2178/2360/2808、PrEN ISO 19840、ASTM B499/D1186/D1400/D7091/E376/G12、BS3900-C5、SSPC-PA2等
Calibrated Certificate
Yes.
Language
Chinese, English
Display screen
2.8-Inch color touchscreen
Interface
USB、Bluetooth
supporting software
PosiSoft Software Suite
Machine Weight
137G (without battery)
Machine size
127*66*25.4mm
Data storage
250000 Measured values, 1000 groups
Test environment
All metal substrates automatically convert measurements in magnetic and nonmagnetic environments
Defelsko calibrated standard
STDS1、STDA1
screen image saving
One hundred.
Protection level
IP65
Measurement speed
More than 180 readings per minute
PosiTector 6000 FNS3
Coating Thickness Gauge
Advanced Coating Thickness Gauge, magnetic and nonmagnetic dual function thickness measurement, range 0~1500μm, error +/- 1%, color touch screen, screen image saving 100, replaceable split probe, supporting PosiSoft software suite.
Defelsko PosiTector 6000 FNS3 Coating Thickness Gauge metal substrate Automatic substrate type identification and measurement Picture

Coating Thickness Gauge selector

Overview

The Defelsko PosiTector 6000 FNS3 Coating Thickness Gauge is a dual-function advanced coating Thickness Gauge manufactured by Devsko, USA, which can be used to measure the thickness of non-conductive coatings on non-ferrous metals as well as non-magnetic coatings on ferrous metals.The PosiTector 6000 FNS3 Coating Thickness Gauge features a high-contrast color LCD display that measures thickness in the 0~1500 micron range and transmits data via USB and Bluetooth wireless technology.Defelsko PosiTector 6000 FNS3 涂层测厚仪探头

Bi-functional:

1. Substrate: ferrous metal (steel)

Coating: Non-magnetic coating

2. Substrate: non-ferrous metal (aluminum, copper)

Coating: Non-conductive coating


New features have been added to the new version of the Defelsko PosiTector console in the United States

Introducing the Defelsko brand

Defelsko PosiTector 6000 FNS3 Coating Thickness Gauge Probe Accuracy

The Defelsko PosiTector 6000 Coating Thickness Gauge can be equipped with a variety of transducers

Comparison of the features of the Defelsko PosiTector 6000 Advanced and Standard models in the United States

Advantages of the protective features of the Defelsko PosiTector 6000 FNS3 Coating Thickness Gauge

Additional features of the Defelsko PosiTector 6000 FNS3 Coating Thickness Gauge

Typical application area of the Defelsko PosiTector 6000 FNS3 coating Thickness Gauge

Why Choose the Defelsko PosiTector 6000 FNS3 Coating Thickness Gauge in the US?

Recommended reading

★《How do you choose the Defelsko PosiTector 6000 Coating Thickness Gauge?》

★Defelsko PosiTector 6000 Series Coating Thickness Gauge Details (Text Version)

FAQ
QWhich imported Coating thickness gauge can directly measure two different Coating thicknesses on the metal surface?
A This Defelsko PosiTector 6000 FNS3 can meet your needs.
QCan 6000FNS3 Thickness Gauge Test Coating thickness on steel plates and Aluminum Panels?
A Yes, this one is dual-use type.
QWhere can I download the software?
A The software download address is attached to the operation manual, please download according to the address in the operation instructions.
QCan the Eletroplating film thickness gauge measure zinc and zinc-nickel alloy layers? The substrate is mainly Q235 or Q345. The thickness of my product is 8μm-100μm. How is the accuracy of the range? I have paint or coating here, because the platings are relatively thin, so I want to buy a more accurate one.
A The Defelsko6000 FN Coating thickness gauge can be tested from 0 to 1500 μm with an accuracy of +/- 1%.
QDo the Defelsko 6000 series thickness gauges come standard with software?
A This does not have a physical software CD, but PosiSoft software can be downloaded for free on the manufacturer's official website for downloading and viewing data reports.
QCan this Coating thickness gauge from Defelsko be replaced with a Miscellaneous probe?
A Hello, yes, Defelsko's hosts are universal.
QWhy can't the Defelsko Coating thickness gauge be charged?
A Hello, there are two solutions: 1. It is equipped with 3 ordinary AA batteries, please open it and replace it; 2. It can also be connected to a computer for direct use, but it cannot be charged (powered by a USB cable).
QTo test the waterproof coating film on the steel substrate, the film thickness is 30-40 microns, is this suitable?
A Hello, PosiTector6000 FNS3 Coating thickness gauge can be tested.
QDo you have the Coating thickness gauge required by ASTMB499 standard?
A This PosiTector 6000 FNS3 Coating thickness gauge will do.
QCopper coated with paint layer, Film thickness around 1200 μm, DeFelsko Do you want to use this 6000FNS3?
A Sure.
