Specifications
| structural form | portal |
| Operation mode | Microcomputer control (all Chinese software operation) |
| Force Measurement Range | 2% -100% of the maximum test force (0.4% -100%) |
| Test force Accuracy | +/- 1 %( +/- 0.5% Special Choice) |
| distortion display error | +/- 1% (or +/- 0.5%) |
| Test force minimum resolution | 0.01N |
| Beam displacement Accuracy | ±1%(±0.5%) |
| Deformation Accuracy | Better than +/- 1 %( +/- 0.5%) |
| Speed regulation range | 0.01-200mm |
| test stroke | > 600mm (can be customized according to customer needs) |
| Test space adjustment mechanism | Servo motor, synchronous belt drive |
| protection function | Overload protection, limit protection |
| Power | 220 V |
| Operating Environment | Room temperature -35 ℃, Humidity 20%~ 80% |
| Fixture form | According to customer requirements, suitable fixtures can be configured, and special fixtures can be customized according to customer requirements. |
