Specifications
| Maximum Impact Energy | 300J/150J |
| Pendulum elevation angle | 150° |
| The distance from the center of the pendulum axis to the center of the strike | 750mm |
| Impact velocity | 5.2m/s |
| Specimen bearing span | 40mm |
| Arc radius of specimen support end | R1-1.5mm |
| Impact knife arc radius | R2-2.5mm |
| Impact arc radius | 30° |
| Impact knife thickness | 16mm |
| Specimen specification | 10mmX10mmX55mm |
| Power | Three-phase four-wire system 50HZ 380V 180W (main motor] |
| standard | GB/T3038-2007、GB/T229-1994 |
| Weight approx | 480kg |
