Specifications
| Vertical burr | ≤12μm |
| Horizontal burr | ≤20μm |
| die life | Normal use ≥ 30,000 times |
| Maximum punching size | L100mmxW140mm (can be customized according to customer requirements) |
| Punching Accuracy | ±0.1mm |
| punching pressure | Max.1T (0.5MPa compressed gas), the recommended pressure for punching and cutting battery pole pieces is 500Kg. |
| die-cutting stroke | 35mm |
| compressed air | 0.5MPa compressed gas, such as the gas used in the glove box is the same as the glove box |
| Dimensions | L350mm*W230mm*H300mm |
| Device Weight | 32kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/45130/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
