Specifications
| Measurement principle | Magnetic Induction + eddy Current |
| Measurement range | 0-500μm |
| Accuracy | 0.7um+1% |
| Host model | SX - standard |
| accessible probe | FN、F、N |
| Calibrated mode | Factory calibrated, zero calibrated |
| Memory | 1000 pcs-FE, 1000 pcs-NFE |
| data transmission | USB2.0 |
| statistical function | n，x，s，min.，max，Kvar，cp，cpk |
| Display information | SX---color screen, backlight |
| Power Supply | 2xAA dry batteries, rechargeable batteries can also be used. |
| Battery life | With 1 reading per second, it can operate continuously for up to 24 hours |
| Instrument size (H x W x L) | 137mm×66mm×23mm |
| instrument Weight | 223g |
| Probe model | Straight probe F1.5A |
| probe end diameter | 6mm |
| Probe minimum headroom height | 85mm |
| Probe minimum sample diameter | 3mm |
| Probe size | 14mm×83mm |
Packing list
Host X1, rubber protective cover X1, calibrated film X2, zero standard sheet (iron) X1, AA battery X2, PHYNIX. USBt transmission, software X1, user manual (Chinese) X1, Encasement box X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/45137/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
