Specifications
| Effective Spreader Width | ≤480mm |
| Coil diameter | 500-700mm |
| power | 1.4KW |
| Power Supply | Three-phase 220V |
| Dimensions | 2650 * 1100 * 1700mm (L * B * H), floor area: 2.3 m2 (including conveyor belt) |
| Weight | 1200kg |
| Equipment power | Servo Control system |
| unroll | With tension control |
| Control system | Touch screen (Kunlun Tongtai) |
| Appearance material | The equipment material is 304 stainless steel protection |
| Vertical cutter installation | 4 |
| Toolbox | 1 (with: Thickness gauge, a set of hexagonal wrenches, a hob adjustment wrench, a hob separation crowbar, a spare screw batch, a screw driver, 3 trachea interfaces) |
| inflated shaft | 2 |
| maintenance | The operating part of the equipment is cleaned with alcohol and anti-rust oil to ensure that the equipment does not rust. |
Packing list
machine x1, manual x1, certificate x1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/45141/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
