PUSHEN BY-III (K) Pendulum Hardness Tester Double pendulum Pendulum damping Hardness Tester

SE
Double pendulum, initial swing angle 6 °, end swing angle 3 °, automatic counting function, can be used to determine film resilience and viscoelasticity.
$1361.00/set
PromotionLoading...
Coupon
Model：
Certificate
Contact
Details SPEC Con CAT

Pushen BY-III(K) Pendulum Hardness TesterSPEC

Pushen BY-III(K) Pendulum Hardness TesterDetails

Pushen BY-III(K) Pendulum Hardness TesterPacking list

SKU
NB045154
pendulum needle
Konig pendulum
Swing rod Weight
200g
Ball diameter
5mm
Initial swing angle
6°
terminal swing angle
3°
swing period
1.4s
Swing Time on Glass
250±10s
counting function
automatic
Dimensions
400×400×780mm
Instrument Weight
500×460×950mm
Shipment Weight
40kg
BY-III(K)
Pendulum Hardness Tester
Double pendulum, initial swing angle 6 °, end swing angle 3 °, automatic counting function, can be used to determine film resilience and viscoelasticity.
PUSHEN BY-III (K) Pendulum Hardness Tester Double pendulum Pendulum damping Hardness Tester Picture

Introduction

The pendulum Hardness Tester provides a method to measure the elasticity and viscoelasticity of a coating film. Place the coating film under the pendulum and measure the swing time of the pendulum to determine the elasticity of the coating film. The principle is to support the two small stainless steel balls on the pendulum Hardness Tester on the dried coating and swing them in a certain period. The softer the coating surface, the faster the swing amplitude of the pendulum attenuates.

Series model

swing needleKonig pendulumPersoz pendulumK+P pendulumdouble pendulum
Swing bar weight200g500g200g/500g120g
Steel ball diameter5mm8mm5mm/8mm8mm
initial swing angle6°12°6°/12°5°
end swing angle3°4°3°/4°2°
swing period1.4s1s1.4s/1s0.625s
swing time on glass250±10s430±15s250±10s/430±15s440±6s
Counting functionautomatic
Dimensions400×400×780mm
Instrument weight500×460×950mm
Shipping weight40kg



FAQ
QIs the price listed on the website the final cost for overseas purchases?
ANo, it isn't. This is the ex-factory price of the product in the Chinese Mainland. In addition to this price, buyers from different countries need to account for additional costs such as shipping fees, tariffs, and others. For specific regional quotes, please consult our customer service or fill out a quotation form.
QWhat is the specific process for purchasing the product?
AFirst, please click on the quotation form on the website and fill in detailed information. Our customer service personnel will then send you a quotation based on your specific country and region, confirming payment and delivery methods. Following this, we proceed with contract signing, payment, and shipment. You can then await delivery.
QWhat should I do if the instrument I purchase needs repair?
AAfter-sales repair for overseas instruments is an unavoidable issue. Our repair terms stipulate that the sender is responsible for the shipping and insurance costs incurred for the repair. Repairs within the warranty period are free, while repair costs beyond the warranty period are determined based on the actual situation.
