PUSHEN BY-III (KP) Pendulum Hardness Tester Double pendulum Pendulum damping Hardness Tester

SE
Double pendulum, initial swing angle 6 ° (K)/12 ° (P), end swing angle 3 ° (K)/4 ° (P), automatic counting function, can be used to determine film resilience and viscoelasticity.
$1454.00/set
PromotionLoading...
Coupon
Model：
Certificate
Contact
Details SPEC Con CAT

Pushen BY-III(KP) Pendulum Hardness TesterSPEC

Pushen BY-III(KP) Pendulum Hardness TesterDetails

Pushen BY-III(KP) Pendulum Hardness TesterPacking list

SKU
NB045156
Swing rod Weight
200g/500g
Ball diameter
5mm/8mm
Initial swing angle
6°/12°
terminal swing angle
3°/4°
swing period
1.4s/1s
Swing Time on Glass
250±10s/430±15s
counting function
automatic
Dimensions
400×400×780mm
Instrument Weight
500×460×950mm
Shipment Weight
40kg
BY-III(KP)
Pendulum Hardness Tester
Double pendulum, initial swing angle 6 ° (K)/12 ° (P), end swing angle 3 ° (K)/4 ° (P), automatic counting function, can be used to determine film resilience and viscoelasticity.
PUSHEN BY-III (KP) Pendulum Hardness Tester Double pendulum Pendulum damping Hardness Tester Picture

Introduction

The pendulum Hardness Tester provides a method to measure the elasticity and viscoelasticity of a coating film. Place the coating film under the pendulum and measure the swing time of the pendulum to determine the elasticity of the coating film. The principle is to support the two small stainless steel balls on the pendulum Hardness Tester on the dried coating and swing them in a certain period. The softer the coating surface, the faster the swing amplitude of the pendulum attenuates.

Series model

swing needleKonig pendulumPersoz pendulumK+P pendulumdouble pendulum
Swing bar weight200g500g200g/500g120g
Steel ball diameter5mm8mm5mm/8mm8mm
initial swing angle6°12°6°/12°5°
end swing angle3°4°3°/4°2°
swing period1.4s1s1.4s/1s0.625s
swing time on glass250±10s430±15s250±10s/430±15s440±6s
Counting functionautomatic
Dimensions400×400×780mm
Instrument weight500×460×950mm
Shipping weight40kg


FAQ
QI want to test the Hardness of automotive paint. Is PUSHEN BY-III (KP) suitable?
A Appropriately, this double pendulum design can measure both Koenig and Persuz Hardness values at the same time. Automotive paints need to investigate the resilience changes at different temperatures, and the 200g/500g double weight configuration of the KP pendulum can more fully reflect the deformation resistance of the paint film.
QThe laboratory needs to do Coating acceptance, choose a single pendulum or a double pendulum hardness gauge?
A The double pendulum model is recommended because the KP pendulum contains two test standards. The Koenig pendulum is suitable for testing soft coatings, and Persuz is more sensitive to hard paints. One set of instruments can meet a variety of Coatings testing needs, and the acceptance data is more authoritative.
