Specifications
| Measurement range | 0~999999 times [logarithmic 0~ lg4.78] (the corresponding folding number can be set to automatically stop) |
| folding angle | Unilateral angle: 135 ° (0~18 0 °） +/- 1 ° adjustable, total angle back and forth: 0~360 ° adjustable |
| Tension adjustment | 4.91N/9.82N/14.73N (1~ 20N adjustable), spring compression at least 17mm |
| Standard upper chuck | Spiral locking fixture with specimen parallel position |
| Upper clamping thickness range | （0.1~2.30）mm |
| Upper clamping width range | （0.1~16.0）mm |
| Upper Clamping Force area | 7.8*6.60mm/51.48mm² |
| Upper clamping torque | 19.95:5.76—Wid 9.85mm |
| Parallel positioning height of specimen | 16.0mm |
| lower folding chuck | Tension change not more than 0.343N |
| The width of the lower folding head is | 19±0.1mm（0.1~20.0mm） |
| Lower clamping torque | 11.9:4.18~Wid 6.71mm |
| Reproducibility | 10%(when 30T), 8%(when 3000T) |
| Specimen length | ≥30mm |
| Upper and lower chuck distance | 20mm |
| The distance between the cracks of the folding mouth | 0.25, 0.5mm, 0.75, 1.00mm four sets of chucks |
| Human Machine Interface | 5.0Inch color touch screen/Chinese and English dual system |
| shutdown condition | Breaking automatic shutdown, setting the number of folding tests to reach shutdown, conduction fracture shutdown |
| Ventilating system | Self-priming cooling system, suitable for fatigue testing |
| printout | modular integrated thermal printer |
| Size Weight | 350*300*480mm |
| Weight | 35kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/45182/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
