Specifications
| Measurement range | ±500kgf；±4900N；±1100Lbf |
| Resolution | 0.01kgf (<100kgf)、0.1kgf (≥100kgf)；0.1N (<1000N)、1N (≥1000N)；0.1Lbf (<1000Lbf)、1Lbf (≥1000Lbf) |
| Accuracy | Level 0.5 |
| Accuracy | +/- 0.5% FS (range) +/- 1 digital peak |
| unit | kgf, N, Lbf |
| Measured value | Peak, instantaneous value |
| show | Four-digit large LCD, forward and reverse dual display |
| shutdown mode | 10 minutes automatic shutdown or manual shutdown |
| Backlight | Blue backlight |
| allowable load | 150% F.s (buzzer alarm when it exceeds 110% F.s) |
| Power | 2 AA batteries or 5V DC Power |
| Operating temperature | 0℃~40℃ |
| Operating humidity | < 80% |
| Operating Environment | No source and corrosive medium around |
| Net Weight | 1165g |
| Host size | 175mmx80mmx36mm |
| Sensors size | 140mmx65mmx105mm |
Packing list
After-sales instructions
Warranty days: 730 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/45218/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
