Specifications
| Spreader Accuracy | ±0.003mm |
| Spreader thickness range | 0.2~10mm |
| Coating speed | 5~ 180Mm/s (< 5mm/s can be customized) |
| Coating size | 500 * 800Mm (application length 0-800mm can be set arbitrarily) |
| Spreader time | Digital display, different speed, time Accuracy control, |
| Heating temperature range | RT+~200℃ |
| Temperature Uniformity | Temperature +/- 3 ℃ |
| Drawdown blade length | 500Mm stainless steel material |
| Host Power | 220V 50HZ 1700W |
| speed control | Infinitely variable speed |
| Bottom plate material | aluminum alloy |
| Optional | Leakage tank, substrate fixing fixture, trimming horizontal height support foot device, Glass plate, Silicone pad and Weight (for applications with uneven thickness of Spreader substrate), application width control baffle |
| Customizable function | Jet system device, UV solid-containing device, automatic inking system |
Packing list
Film Applicator X1, Drawdown blade X1, Product manual X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/45225/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
