Specifications
| Drawdown blade Accuracy | ±10% |
| Spreader thickness range | 10-300μm |
| Coating speed | 5-200mm/s |
| Coating size | 800mm*800mm |
| Spreader speed | Digital display, different speeds |
| Vacuum Area | 800 * 800Mm (adsorption of about 1mm thick metal plate) |
| Vacuum aperture | Φ1.2mm |
| Vacuum hole spacing | 20*20mm |
| Vacuum pump size | 380*180*280mm |
| Coating rod specification | 1 China wire rod + 1 imported wire rod with Accuracy up to 1μm, effective application width 300mm (Spreader thickness is determined according to the wire rod model) |
| Host Power | 220V 50Hz |
| speed control | Infinitely variable speed |
| Coating table material | aluminum alloy |
| Optional | Leakage tank, substrate fixing fixture, trimming horizontal height support foot device, Glass plate, Silicone pad and Weight (for applications with uneven thickness of Spreader substrate), application width control baffle |
| Customizable function | Jet system device, UV solid-containing device, automatic inking system |
| Matching drawdown blade | Yes. |
| Applicable viscosity range of gluing | 4000-8000cp |
| unit | Platform |
Packing list
Film Applicator X1, External Vacuum Pump X1, Drawdown blade X1, Import bar X1, Product manual X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/45239/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
