Specifications
| Measurement range -FNU turbidity mode | 0.00 to 9.99、10.0 to 99.9、100 to 1000FNU |
| Resolution-FNU turbidity mode | 0.01FNU、0.1FNU、1FNU |
| Measurement Accuracy -FNU turbidity mode | +/- 2% reading (ignoring stray light error); |
| Measurement range -FAU turbidity mode | 10.0 to 99.9FAU、100 to 4000FAU |
| Resolution-FAU turbidity mode | 0.1FAU、1FAU |
| Measurement Accuracy -FAU turbidity mode | Reading +/- 10% |
| Measurement range - turbidity nonlinearity | 0.00 to 9.99、10.0 to 99.9、100 to 1000NTU；0.00 to 9.99、10.0 to 99.9、100 to 245EBC |
| Resolution - turbidity nonlinearity | 0.01NTU、0.1NTU、1NTU；0.01EBC、0.1EBC、1EBC |
| Measurement Accuracy - turbidity nonlinearity | +/- 2% + stray light error of reading (@25 ℃/77 ° F) |
| Measurement range - turbidity linearity | 0.00 to 9.99、10.0 to 99.9、100 to 4000NTU；0.00 to 9.99、10.0 to 99.9、100 to 980EBC |
| Resolution - turbidity linearity | 0.01NTU、0.1NTU、1NTU；0.01EBC、0.1EBC、1EBC |
| Measurement Accuracy - turbidity linearity | +/- 2% of reading + stray light error (≤ 1000NTU); +/- 5% of reading (> 1000NTU) (@25 ℃/77 ° F) |
| range conversion | Automatic range conversion |
| Turbidity Repeatability | +/- 1% of the reading or 0.02 NTU (0.15 Nephelos; 0.01 EBC), whichever is greater |
| minimum detection limit | <0.1NTU(0.05EBC) |
| Method/standard | Compliant with ISO7027 turbidity measurement standard |
| Measurement mode | Ordinary measurement, continuous measurement, average measurement |
| Calibrated mode | Manual calibration with built-in standard calibrating points: < 0.1, 15, 100, 750FNU and 2000NTU |
| Optical inspection system | Custom Dedicated Receiver & Light source System |
| data management | USB Interface, 200 sets of measurement Data storage |
| Power mode | 230V/50Hz 20W; if you don't do how to operate it for 15 minutes, it will automatically shut down. |
| Operating Environment | 0 to 50°C(32 to 122°F),RH max 95% 无冷凝 |
| Size Weight | Host size: 230 × 200 × 145mm, host Weight: 2.5kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/45264/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
