Specifications
| Coating method | Rod |
| Coating speed | 1~ 300Mm/s stepless speed regulation (can be customized) |
| Substrate clamping method | fixture |
| Coating table material | Glass plate |
| Coating table size | 600*300mm |
| Effective coating Area | 400 * 300Mm (can be customized) |
| Film thickness | Controlled by bar, with high-precision imported bar |
| Mayer Rod Accuracy | ±0.001mm |
| Drive motor | Servo motor |
| Power | 600w |
| Operating language | Chinese (can be customized in English) |
| Display | Color LCD touch screen |
| Host Power Supply | 220V/50HZ (can be customized 110V/60HZ) |
| Dimension | 658*438*205mm（L*W*H） |
| Weight | 39.7kg |
| optional feature | Drawdown blade, heating, vacuum adsorption |
Packing list
Machine X1, manual X1, fixture X1, doctor blade x1, imported wire rod X1, certificate X1
After-sales instructions
Warranty days: 730 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/45279/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
