Specifications
| Rated Voltage | AC 220V |
| Rated Frequency | 50/60Hz |
| Input Power | 500W |
| output power | 320W |
| drive type | DC brushless motor |
| Output torque of stirring shaft | 200N.cm |
| Output peak torque of stirring shaft | 320N.cm |
| Allowable continuous running time | 100% |
| Rotation speed control | Control knob |
| Speed regulation mode | stepless |
| Speed range | 50~3000rpm |
| Timer Range | 1~6000min |
| Running status display | TFT LCD screen |
| Rotation speed dynamic detection function | Yes |
| Rotation speed memory function | Yes |
| Overload protection function | Yes |
| Temperature display | Yes |
| keylock function | Yes |
| Torque measurement | trend |
| Wireless Controller 200 meters | optional module |
| Temperature measurement | optional module |
| External temperature sensor interface | PT1000 |
| Measurement range | -50~400℃ |
| Measurement Accuracy | 0.1K |
| Stirringrod fixing method | Quick turn chuck |
| Rotary collet clamping range | 3~13mm |
| Hollow shaft (can be inserted in stop state) | 12mm |
| Impeller configuration | Four Blade Spiral Impeller |
| Processing Capacity | 100L |
| maximum viscosity | 130000mpa.s |
| Environmental temperature | Less than 40 ℃ |
| Environmental humidity | Not more than 80% |
| Protection level | IP40 |
| Dimensions of the whole machine | 600x320x220mm |
| Machine Weight | 15Kg |
Packing list
After-sales instructions
Warranty days: 365 days
1.仪器设备非人为造成的产品质量问题，在质保期内厂家提供免费质保服务；
2.易损易耗配件不存在质保期，收到货发现产品质量问题，请在7天内申请退换货，逾期不候；
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/45686/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
