Specifications
| Rated Voltage | AC110V |
| Rated Frequency | 50/60Hz |
| Input Power | 850W |
| output power | 500W |
| Rated torque | 35N.cm |
| Duty Cycle | S1 (continuous) |
| Operation control method | Touch knob |
| Speed range | 1000~14000rpm |
| Rotation speed Control mode | stepless |
| Rotation speed digital display | TFT-LCD |
| Timer Range | 1~1000min |
| Real-time torque Linear dispersion display | Yes |
| Real-time Current and Power Display | Yes |
| Real-time overload protection | Yes |
| Work head Max Torque | 60N.cm |
| Rotor maximum linear speed | 18m/s |
| Work head material | SS304 stainless steel |
| Working head diameter | 70mm |
| Minimum immersion liquid height | 50mm |
| Maximum immersion liquid height | 236mm |
| Stator standard configuration | 5mm² 20mm² 50mm² |
| Processing Capacity | 500～40000ml |
| Max. Processing Viscosity | 8000mPa.s |
| Environmental temperature | Not more than 40 ℃ |
| Allowable Relative Humidity | Not more than 80% |
| Dimension | 215x310x700mm |
| Machine Weight | 10kg |
Packing list
After-sales instructions
Warranty days: 365 days
1.仪器设备非人为造成的产品质量问题，在质保期内厂家提供免费质保服务；
2.易损易耗配件不存在质保期，收到货发现产品质量问题，请在7天内申请退换货，逾期不候；
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/45695/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
