Specifications
| Drawdown blade Accuracy | ±0.003mm |
| Drawdown blade thickness range | 0.01~10mm |
| Coating speed | 5~ 180Mm/s (< 5mm/s can be customized) |
| Coating size | 300*400mm |
| Coating rod specification | Accuracy 0.001mm, effective application width 300mm (Spreader thickness is determined according to the bar model) |
| Drawdown blade length | 400MM material/stainless steel |
| Host Power | 220V 50Hz 1700W |
| Dimensions | 626*410*520mm |
| Weight | Net Weight 55KG |
| speed control | Infinitely variable speed |
| Bottom plate material | aluminum alloy |
| Optional | Leakage tank, substrate fixing fixture, trimming horizontal height support foot device, Glass plate, Silicone pad and Weight (for applications with uneven thickness of Spreader substrate), application width control baffle |
| Spreader Accuracy | 0.001mm |
| UV light curing area | 300*400mm |
| UV main peak wave | 36nm |
| UV Power | 400*2W |
| UV light curing wavelength | 350-450nm |
| switch | Aviation plug/separate switch |
| Light source spacing | 18*18mm |
| Light board height from Spreader | 20Mm (support customized adjustable height) |
Packing list
Film Applicator X1, China bar X1, Drawdown blade X1, UV curing device x1, product manual X1
After-sales instructions
Warranty days: 365 days
