Specifications
| Spreader Accuracy | ±0.003mm |
| Spreader thickness range | 0.02~ 10Mm drawdown blade can be lifted |
| Coating speed | 5~ 180Mm/s (< 5mm/s can be customized) |
| Coating size | 600*900mm |
| Spreader speed | Digital display, different speeds |
| Vacuum Area | 600 * 900Mm (can be customized) |
| Vacuum aperture | Φ1.2mm |
| hole spacing | 20*20mm |
| Drawdown blade | length |
| Host Power | 220V 50Hz |
| Weight | Net Weight 65KG |
| speed control | Infinitely variable speed |
| Bottom plate material | aluminum alloy |
| Vacuum pump size | 380*180*280mm |
| Optional | Leakage tank, substrate fixing fixture, trimming horizontal height support foot device, Glass plate, Silicone pad and Weight (for applications with uneven thickness of Spreader substrate), application width control baffle |
| Customizable function | Jet system device, UV solid-containing device, automatic inking system |
Packing list
Film Applicator X1, Drawdown blade x1, Product manual X1
