Specifications
| Drawdown blade Accuracy | ±0.02mm |
| Drawdown blade thickness range | 0~10mm |
| Coating speed | 5~ 180Mm/s (< 5mm/s can be customized) |
| Spreader speed | Digital display, different speeds |
| Coating rod specification | Accuracy 0.01mm (Spreader thickness is determined according to the rod model) |
| Host Power | 220V 50Hz |
| Dimensions | Non-standard customization, subject to the actual order. |
| speed control | Infinitely variable speed |
| Bottom plate material | aluminum alloy |
| Customizable function | Automatic inking system |
| Customizable function | Jet system device, UV solid inclusion device |
| Feeding principle | Air source pressure flows out |
| Feed Sport Mode | Reciprocating linear motion |
| Feeding back and forth traverse speed | 2-150mm/s |
| spit Volume | Adjustable (by adjusting the air pressure and the operating speed of the discharge port) |
| Shaft drive mode | Timer belt |
| Feeding system air source | 0.6Mpa, can be connected to the trachea of φ 8 (self-matching) |
| Power Voltage of feeding system | 220V,50Hz |
| Tank pressure | Maximum withstand 8Mpa |
| Material of feeding barrel | 304 stainless steel with a wall thickness of 4mm |
| Feeding drum configuration | Safety valve, pressure regulating valve, pressure gauge, relief valve |
| Speed regulation Accuracy | 1mm/s |
| Heating Temperature range | RT+~180℃ |
| Temperature Accuracy | ±3℃ |
| Feeding drum Volume | 3L |
| Vacuum aperture | Φ1.2mm |
| hole spacing | 20*20mm |
Packing list
Film Applicator X1, Drawdown blade X1, Import bar X1, Automatic inking system x1, Product manual X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/45770/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
