Specifications
| Drawdown blade Accuracy | ±10% |
| Drawdown blade film thickness | 0~10mm |
| Coating speed | 5~ 180Mm/s (< 5mm/s can be customized) |
| Coating size | 850mm*1000mm |
| Spreader speed | Digital display, different speeds |
| Coating rod specification | Accuracy +/- 3% (Spreader thickness according to rod model) |
| Host Power | 220V 50Hz |
| Dimensions | Non-standard customization, subject to the actual order. |
| speed control | Infinitely variable speed |
| Bottom plate material | aluminum alloy |
| Spreader Accuracy | ±3% |
| Customizable function | Automatic inking system |
| Customizable function | Jet system device, UV solid inclusion device |
| Feeding principle | Air source pressure flows out |
| Feed Sport Mode | Reciprocating linear motion |
| Feeding back and forth traverse speed | 2-150mm/s |
| spit Volume | Adjustable (by adjusting the air pressure and the operating speed of the discharge port) |
| Shaft drive mode | Timer belt |
| Feeding system air source | 0.6Mpa, can be connected to the trachea of φ 8 (self-matching) |
| Power Voltage of feeding system | 220V,50Hz |
| Tank pressure | Maximum withstand 8Mpa |
| Material of feeding barrel | 304 stainless steel with a wall thickness of 4mm |
| Feeding drum configuration | Safety valve, pressure regulating valve, pressure gauge, relief valve |
| Optional | Leakage tank, substrate fixing fixture, trimming horizontal height support foot device, Glass plate, Silicone pad and Weight (for applications with uneven thickness of Spreader substrate), application width control baffle |
| Speed regulation Accuracy | 1mm/s |
| Feeding drum Volume | 3L |
Packing list
Film Applicator X1, Drawdown blade x1, Import bar X2, Automatic inking system x1, Cost recovery tank x1, Product manual X1
After-sales instructions
Warranty days: 365 days
