Specifications
| Spreader process | Roll → Scratch → Drying → Roll |
| Effective Spreader Width | Max.Φ1500mm |
| Coating Method | scraping |
| Cutting head type | Adjustable drawdown blade |
| Indication display | digital display |
| WFT | 0.005-3mm |
| Regulator Graduation | 0.001mm |
| Spreader Accuracy | ±10% |
| Coating Speed | 1-10M/min (adjustable) |
| unwinding method | Inflatable shaft unwinding |
| winding method | Inflatable shaft winding |
| Outer diameter of winding air expansion shaft | 3-Inch expansion shaft, load-bearing 50KG |
| maximum discharge | Max.Φ1500mm |
| Maximum charge | Max.Φ1500mm |
| Drying temperature range | RT+~200℃ |
| Temperature control Accuracy | ±5℃ |
| Heating method | hot air circulation |
| Oven length | 1M/section |
| Total length of drying tunnel | 12m |
| Drying power | 1KW/section |
| Tension control range | 1~10N |
| Tension control Accuracy | ±0.5N |
| Motor type | Servo motor |
| control mode | PLC + touch screen |
| Human Machine Interface | Color touch screen |
| tension control | automatic |
| Deviation Correction control mode | automatic |
| Film thickness control | manual |
| Fitting method | Roll fit |
| Fitting speed | 0.1~ 10M/min (adjustable) |
| fit width | Max.Φ1500mm |
| gas source | 0.5~ 0.8MPa compressed air |
| Applicable coil type | Plastic film, metal foil, paper, non-woven fabric, etc |
| Spreader type | Water-based paints, solar-based paints, UV coatings, etc |
| Operating environment temperature | 10℃ ~ 40℃ |
| Operating Environment humidity | 30～90%RH |
| Power Supply | 380V, 50Hz, three-phase five-wire system |
| Total power | 45KW (subject to actual customization) |
| Dimensions | About 4000mm*2000mm*1600mm (subject to actual customization) |
| total | Subject to actual customization |
| Tension control mode | Automatic constant tension |
Packing list
Machine x1, Manual x1, Encasement List x1, Certificate of Conformity x1
After-sales instructions
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/45780/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
