Specifications
| vacuum | -0.098MPa |
| structural form | The power mixer and the press are installed on the same workbench |
| Speed regulation range | Rotation: 0~70rpm, Rotation: 0~80rpm; High speed: 0~1450rpm. |
| Low speed shaft | Two-axis folded blade type, two scraped bottoms, one scraped edge |
| High speed shaft | Single high-speed shaft, one-layer φ 60 dispersion disc structure |
| Cover lifting method | hydraulic lift |
| Cover lift height | 300mm |
| Temperature measurement method | Static in-cylinder temperature measurement |
| Kettle body positioning | Adopt propulsion guide device and V-shaped track positioning. |
| Total power | 6.75kw |
| Power Supply | AC：3*380V、50HZ |
| Dimensions | 1000*700*1700mm |
| Weight | Approx. 800kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/45794/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
