Specifications
| Measurement range | (5～3000)mN |
| Test speed | 1.2mm/s(0.1~20mm/s) (1~500mm/min) |
| total itinerary | 16mm |
| Measurement time | 15s |
| Resolution | 0.1mN |
| Precision | ±1% |
| Indication variability | ≤1% |
| Probe indentation depth | 8+0.5mm |
| Probe width | 400±0.5mm |
| narrow width of sample stage | 5mm、6.35mm、10mm、20mm |
| test leverage | 32:73 |
| Moment group | 20/25 - group, 10/16 - group, 6.35/16 - group, 5/16 - group |
| Test Weight | 100g |
| Sample table slot-die parallelism error on both sides | ≤0.05mm |
| Test Load Plate | 304 stainless steel light plate |
| Report printing | Comes with a micro thermal printer |
| Weight | Approx. 30 kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
Non-artificially caused product quality problems, the manufacturer provides 1 year free warranty service
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/45806/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
