Specifications
| Spreader process | Unwinding → scraping → drying → scraping → drying → film laminating → winding |
| Film speed | 1-10m/min |
| Application width | 100-500Mm adjustable |
| WFT | 0.005-3mm |
| Device size | Approx. Length 1800X Width 800X Height 1600mm |
| maximum discharge | 500mm |
| Maximum charge | 500mm |
| Effective application width | 500mm |
| Drying Temperature range | Room temperature -200 ℃ |
| Drying tunnel length | 1m |
| Drying Power | 1KW |
| Power | 220V/2.5KW |
| rubber roller | Heating temperature: room temperature~ 200 ℃ |
| Spreader head | Drawdown blade |
Packing list
Machine x1, Manual x1, Encasement List x1, Certificate of Conformity x1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/45835/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
