Specifications
| pulling force | Up to 30kN (model 92NML, plate thickness up to 1.5mm) |
| pulling force | Maximum 60kN (model 92NM, plate thickness up to 3.5mm) |
| Punch stroke indication | Digital (Accuracy 0.1mm, standard) |
| Hydraulic tank Capacity and HY | 5L,ENCLO-57 |
| size | 1066×585×1250mm |
| Maximum punch stroke | About 45mm |
| Drawing speed | Up to 150mm/min |
| blank holder force | Maximum 12kN |
| Power | 400V3~，50Hz |
| power consumption | 0.50kw |
| paper pressing force | 0 to 5kN |
| Net Weight | Approx. 300kg |
