China

BENTING CBGL-850B Electric Forced Air Drying Oven 2KW/850L

SE
Temperature range RT + 10-300 ℃, Temperature resolution 0.1 ℃, Power 2.0kw, dedicated function keys to achieve temperature setting, PID temperature controller, microcomputer temperature control, accurate temperature control, high-precision, large capacity, high efficiency, safety, wide range.
$5512.00/set
PromotionLoading...
Coupon
Model：
Certificate
Contact
Details SPEC Con CAT

BenTing CBGL-850B Electric Forced Air Drying OvenSPEC

BenTing CBGL-850B Electric Forced Air Drying OvenDetails

BenTing CBGL-850B Electric Forced Air Drying OvenPacking list

SKU
NB045877
Thermostatic mode
Fan circulation
Power Supply
380V 50HZ
Temperature range
RT+10-300℃
Temperature Resolution
0.1℃
Temperature Fluctuation
1℃
Power
2.0kw
Temperature Uniformity
±5℃%
Interior
Stainless steel plate production
Exterior
Cold rolled steel plate surface with antimicrobial resistance painting
Thermal Insulation
Flame retardant fiberglass cotton
Heating device
Stainless steel heating pipe
Door opening method
Manual double door
Control mode
PID
Temperature Display mode
liquid crystal display
Temperature setting
Tap the button to set
Timer
0-9999 minutes
Operational Features
Timing operation, temperature deviation correction, menu lock, power failure memory.
Optional Accessories
485 interface, printer, programmable temperature Controller
Independent Overtemperature Protection
Yes.
Safety Devices
Over-temperature alarm, power failure
Inner size (W * D * H)
1700×1000×500mm
External dimension
Subject to actual situation
Inner Volume
850L
Shelf number
2 pieces/movable
Shelf load bearing
25KG
CBGL-850B
Electric Forced Air Drying Oven
Temperature range RT + 10-300 ℃, Temperature resolution 0.1 ℃, Power 2.0kw, dedicated function keys to achieve temperature setting, PID temperature controller, microcomputer temperature control, accurate temperature control, high-precision, large capacity, high efficiency, safety, wide range.
BENTING CBGL-850B Electric Forced Air Drying Oven 2KW/850L Picture

Introduction

CBGL-850B electric Forced Air Drying Oven has a novel vertical design. The outer shell of the box is made of high-quality steel plates. The surface is treated with electrostatic spraying technology. The studio is made of stainless steel and treated with anti-corrosion technology. The four corners are in the form of arc transitions, the spacing between partitions is adjustable, and the air duct side panels and bottom heating cover are of quick-detachable structure for easy cleaning. The door adopts a new structure and has good heat insulation effect. It is equipped with a double-layer tempered glass large viewing window in the middle, equipped with a lock-type elastic adjustment door lock and high-temperature resistant silicone sealing strip to ensure good sealing and prevent heat loss.

Features

  • High precision, large capacity, high efficiency, safety and wide range.

  • PID temperature controller and microcomputer temperature control ensure accurate temperature control.

  • Dedicated function keys enable temperature setting.

  • Auxiliary menu to realize over-Voltage alarm, deviation correction and menu locking.

FAQ
QOur laboratory needs to do thermostatic drying of large quantities of samples, which electric air blowing dryer should be selected?
A BENTING CBGL-850B electric air blowing dryer is recommended. It has a large capacity of 850 liters, and the inner cavity size reaches 1700 × 1000 × 500mm, which can place a large number of samples at the same time. It adopts the fan cycle thermostatic method, and the temperature distribution uniformity is +/- 5 ° C. It is suitable for batch processing of samples in the laboratory, which can effectively improve work efficiency.
QWe need a drying oven with data recording function, can this one satisfy it?
A Yes, CBGL-850B supports optional 485 interface and printer function, which can record temperature data in real time and print it out. With 0-9999 minutes timing function and power failure memory function, it ensures the integrity and traceability of experimental data, and is suitable for scientific research and quality control applications that need to record experimental processes.
QDrying ovens require remote monitoring and data logging. Are there any models with these functions?
A CBGL-850B supports optional 485 interface and printer, which can realize remote monitoring and data printing. The built-in programmable temperature controller can set complex temperature Linear dispersion, which is suitable for occasions where the drying process needs to be recorded. Safety devices such as over-temperature alarm ensure safe operation.
Standard
