BENTING CBGL-1000B Electric Forced Air Drying Oven 300 ℃/1000L

SE
1000L volume, Temperature range RT + 10-300 ℃, Temperature resolution 0.1 ℃, Power 2.0kw, dedicated function keys to achieve temperature setting, PID temperature controller, microcomputer temperature control, accurate temperature control, high-precision, large capacity, high efficiency, safety, wide range.
$4548.00/set
PromotionLoading...
Coupon
Model：
Certificate
Contact
Details SPEC Con CAT
Similar products

BenTing CBGL-1000B Electric Forced Air Drying OvenSPEC

BenTing CBGL-1000B Electric Forced Air Drying OvenDetails

BenTing CBGL-1000B Electric Forced Air Drying OvenPacking list

SKU
NB045880
Thermostatic mode
Fan circulation
Power Supply
380V 50HZ
Temperature range
RT+10-300℃
Temperature Resolution
0.1℃
Temperature Fluctuation
1℃
Power
2.0kw
Temperature Uniformity
±5℃%
Interior
Stainless steel plate production
Exterior
Cold rolled steel plate surface with antimicrobial resistance painting
Thermal Insulation
Flame retardant fiberglass cotton
Heating device
Stainless steel heating pipe
Door opening method
Manual double door
Control mode
PID
Temperature Display mode
liquid crystal display
Temperature setting
Tap the button to set
Timer
0-9999 minutes
Operational Features
Timing operation, temperature deviation correction, menu lock, power failure memory.
Optional Accessories
485 interface, printer, programmable temperature Controller
Independent Overtemperature Protection
Yes.
Safety Devices
Over-temperature alarm, power failure
Inner size (W * D * H)
1600×800×800mm
External dimension
Subject to actual situation
Inner Volume
1000L
Shelf number
2 pieces/movable
Shelf load bearing
25KG
CBGL-1000B
Electric Forced Air Drying Oven
1000L volume, Temperature range RT + 10-300 ℃, Temperature resolution 0.1 ℃, Power 2.0kw, dedicated function keys to achieve temperature setting, PID temperature controller, microcomputer temperature control, accurate temperature control, high-precision, large capacity, high efficiency, safety, wide range.
BENTING CBGL-1000B Electric Forced Air Drying Oven 300 ℃/1000L Picture

Introduction

CBGL-1000B electric Forced Air Drying Oven has a novel vertical design. The outer shell of the box is made of high-quality steel plates. The surface is treated with electrostatic spraying technology. The studio is made of stainless steel and treated with anti-corrosion technology. The four corners are in the form of arc transitions, the spacing between partitions is adjustable, and the air duct side panels and bottom heating cover are of quick-detachable structure for easy cleaning. The door adopts a new structure and has good heat insulation effect. It is equipped with a double-layer tempered glass large viewing window in the middle, equipped with a lock-type elastic adjustment door lock and high-temperature resistant silicone sealing strip to ensure good sealing and prevent heat loss.

Features

  • High precision, large capacity, high efficiency, safety and wide range.

  • PID temperature controller and microcomputer temperature control ensure accurate temperature control.

  • Dedicated function keys enable temperature setting.

  • Auxiliary menu to realize over-Voltage alarm, deviation correction and menu locking.

FAQ
QI would like to buy a drying oven for sample drying in the lab, what do you recommend?
A Recommended BENTING CBGL-1000B electric air blowing dryer, it uses PID microcomputer temperature control, temperature accuracy up to 0.1 ℃, suitable for laboratory temperature requirements of strict sample drying. Fan circulation system to ensure uniform temperature inside the box, stainless steel studio easy to clean, can avoid sample cross contamination.
QOur factory needs to handle aging testing of large quantities of electronic components. Which device should I choose?
A CBGL-1000B is suitable, its 1000L large capacity and double door design facilitate bulk placement of electronic components. Temperature range RT + 10-300 ℃ covers common aging test requirements, Shelf load-bearing 25KG and adjustable spacing can flexibly adapt to different size components. Independent temperature limit and over-temperature alarm function ensure safe and reliable testing process.
QWe need a drying oven that can record temperature data. Does this support it?
A Yes, CBGL-1000B supports optional 485 interface and printer function, which can record and output temperature Linear dispersion data in real time. Optional with programmable temperature controller, it can also realize multi-stage temperature programming, suitable for Quality control or R & D applications that require data traceability.
QI would like to buy a drying oven for laboratory sample drying. Any recommendations?
A CBGL-1000B electric air blowing dryer adopts PID microcomputer temperature control, with a temperature accuracy of 0.1 ° C, which is especially suitable for drying samples with high temperature requirements in the laboratory. The fan circulation system can ensure uniform temperature in the box and avoid uneven heating of samples.
QWhat industries is this drying oven suitable for?
A This 1000L large-capacity drying oven is widely used in the pharmaceutical, chemical, food and other industries. For example, the pharmaceutical industry is used for instrument drying, the chemical industry is used for material heat treatment, and the food industry is used for raw material drying. Its stainless steel liner is easy to clean, corrosion resistant, and can meet the hygiene requirements of various industries.
QI need a drying oven that can be timed and remotely monitored. Can this one satisfy it?
A Absolutely! CBGL-1000B comes with 0-9999 minutes timing function, and can also be equipped with 485 interface for remote monitoring. Its PID temperature control is stable, with over-temperature protection and power failure memory functions, it is smart and safe to use.
QWhat are the advantages of double-decked tempered glass observation windows?
A The observation window design allows the operator to observe the internal situation in real time, while double-decked tempered Glass can effectively insulate and ensure the temperature stability in the box, while the lock-type elastic adjustment door lock and high temperature silicone sealing strip provide good sealing and safety.
QTemperature resolution and Temperature stability?
A Temperature resolution of 0.1 ° C and Temperature stability of +/- 1 ° C ensure accurate monitoring and control of temperature changes during operation.
QSafety protection measures of CBGL-1000B?
A The equipment is equipped with over-temperature alarm and power-off memory functions to ensure timely alarm and record set parameters in abnormal situations to ensure the safe conduct of experiments.
