Specifications
| Coating method | Slot-die Spreader |
| compound velocity | 1-10M/min (slow compounding speed, servo control, adjustable above 0.1m/min) |
| WFT | 0.005-3mm |
| Device size | Approx. Length 1800X Width 800X Height 1600mm |
| maximum discharge | 300mm |
| Maximum charge | 300mm |
| Coating size | Max.300mm |
| Drying Temperature range | Room temperature -200 ℃ |
| Drying tunnel length | 1m |
| Drying Power | 1KW |
| Power | 220V/2.5KW |
| Composite rubber roller | Heating temperature: room temperature~ 200 ℃ |
| Composite Accuracy | 0.5mm |
| motor | Servo motor |
Packing list
Machine x1, Manual x1, Encasement List x1, Certificate of Conformity x1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/45883/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
