Specifications
| Rated Voltage | AC 220V/50 Hz |
| output power | 500W |
| Rotation speed adjustment range | 300～11000 rpm |
| Rotation speed dynamic detection function | Yes |
| Overload protection | Yes |
| Rotor maximum linear velocity | 18 m/s |
| Work head material | Stainless steel 304 # |
| rotor diameter | Φ30 |
| stator diameter | Φ35 |
| Maximum immersion liquid height | 60mm |
| Special airtight glass bottle | 1000Ml optional |
| Stator standard configuration | One mesh, one round hole, and one long hole working head each. |
| Processing Capacity (H2O) | 100～4000 ml |
| Max. Processing Viscosity | 10000 mPa.s |
| Environmental temperature | Not more than 40 ℃ |
| Allowable Relative Humidity | Not more than 80% |
| Dimensions of the whole machine | 215×310×720 mm |
| Machine Weight | 25 kg |
Packing list
machine x1, manual x1, certificate x1
After-sales instructions
Warranty days: 365 days
