Specifications
| supply Voltage | AC220V,50Hz |
| Max Power | 3.5KW (including compressor + peristaltic pump about 1.5KW) |
| Ultrasonic Nebulizer | 40KHz 130W |
| liquid viscosity | 1-50mPa·s(cP) |
| Nozzle stroke | X-Y-Z axis Max 190mm |
| Traverse speed | 10-180mm/min (x-axis direction) 10-180mm/min (Y-axis direction) |
| Heating substrate substrate | 150mm×150mm |
| Max temperature | 500℃ |
| Temperature control mode | AI-PID temperature control |
| Drip coating tank Capacity | 50mL/250mL (with two large and small jars) |
| Peristaltic pump liquid separation rate | 0.006-41mL/min |
| Control method | Industrial control computer + instrument panel |
| Machine size | 850×850×1450mm |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
