Specifications
| supply Voltage | AC220V,50Hz |
| maximum temperature | 500℃ |
| Spray booth | 690×690×790mm |
| Temperature control mode | Al-PID temperature control |
| Atomization head | High Voltage air atomization nozzle X3 Each nozzle is equipped with a high Voltage gas drive baffle to prevent dripping |
| pressure regulator | Adjustable compressed air intake |
| Maximum Power | 3.5KW (including compressor + peristaltic pump about 1.5KW) |
| liquid viscosity | 1-50mPa·s(cP) |
| Nozzle stroke | X-Y axis up to 180mm |
| Traverse speed | 0-250Mm/s (x-axis direction) 0-250mm/s (Y-axis direction) |
| Heating substrate substrate | 200×200mm |
| Drip coating tank Capacity | 50mL/250mL/50mL (with three jars, one large, two small) |
| Peristaltic pump liquid separation rate | 0.006-41mL/min |
| Vacuum pump | Two-stage rotary vane vacuum pump |
| vacuum gauge | Mechanical vacuum gauge |
| Ultimate Vacuum | ≤5000Pa |
| Control method | Industrial control computer + instrument panel |
| Machine size | 900×900×1750mm |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
