Specifications
| Speed range | 0~10000rpm |
| Acceleration range | 100~5000rpm/s |
| Rotation speed resolution | 1rpm |
| single step time | 3000s |
| Suitable substrate | Diameter ≤ 8 inches (200mm) |
| Cavity material | polytetrafluoride |
| Epoxy method | Manual glue drop, optional precision syringe pump |
| Linear dispersion | Linear dispersion 5 segments each, a total of 5 Linear dispersion can be stored |
| pumping rate | 50L/min |
| vacuum pump | Dry mechanical pump |
| heating temperature | RT+~200℃ |
| Heating part | Upper cover heating |
| Power supply Voltage | AC220V 50/60Hz |
| Extraction port | φ 8mm quick screw interface |
| Human Machine Interface | 7 inch high definition LCD touch screen |
| Machine Weight | 12kg |
| Machine size | 290*365*260mm |
Packing list
Host X1, suction cup 10mmx1, suction cup 25mmx1, suction cup 55mmx1, suction cup 100mm x1, oil-free vacuum pump x1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1.仪器设备非人为造成的产品质量问题，在质保期内厂家提供免费质保服务；
2.易损易耗配件不存在质保期，收到货发现产品质量问题，请在7天内申请退换货，逾期不候；
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/45923/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
