Specifications
| Application range of protective layer thickness (mm) | ϕ 6~Ф50 |
| Test range (mm) | The first range: 1~ 90; the second range: 5~ 185 |
| Protective layer thickness MPE (mm) | ±1（1~70）；±2（60~100）；±4（80~180） |
| Diameter measurement application range (mm) | ϕ 6~Ф50 |
| Maximum error of diameter measurement (specification) | ±1 |
| scan mode | Thickness mode, grid view, profile mode, waveform mode, JGJ detection |
| Scanning range | borderless |
| data transmission mode | USB |
| Display | 2.8-Inch high-resolution color LCD screen (320 × 240 pixels) |
| Power Supply | Built-in high-Capacity lithium battery |
| Set the shutdown time | 5m、10m、15m、30m、60m、90m |
| With error correction | Error correction range: -3.0~ + 3.0 (i.e. +/- 0.5, +/- 1.0, +/- 1.5, +/- 2.0, +/- 2.5, +/- 3.0) |
| Key mode | Silicone keyboard |
| Operating temperature | -10℃~+42℃ |
| Volume (mm) | 219×92×106 |
| Weight | 0.6kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/45994/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
