Specifications
| Measurement principle | magnetic induction |
| Measuring range | 0 ~ 1250µm |
| margin of error | ±3% |
| resolution | 0.1µm |
| Minimum measurement surface | F7mm |
| Minimum radius of curvature | Convex 1.5mm; Concave 9mm |
| thinnest matrix | 0.5mm |
| probe | F1 Split Probe |
| icon function | without |
| Power | 2 * AAA alkalinity battery |
| Calibrated Certificate | without |
| Language | Chinese |
| Display screen | LCD |
| supporting software | without |
| Total Weight | F1/165g |
| Complete-built unit size | 150*55.5*23mm |
| Operating Temperature | 0~40℃ |
| data storage | 500 measurements |
| Relative Humidity | 20~90%RH |
Packing list
Host x1, probe x1, standard test piece x1, substrate x1, AAA alkaline battery x1, certificate x1, manual x1, Encasement box x1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/4601/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
