Specifications
| Coating method | Wire rod |
| Coating speed | 2~200mm/s |
| Work surface width | 400Mmx300mm (Miscellaneous size can be customized) |
| Host Power Supply | Single phase 220V 50Hz 100VA |
| Weight | 60kg |
| Dimension | 622*400*280mm |
| Heating mode | Upper infrared heating |
| Heating Temperature range | RT+~180℃ |
| Temperature Accuracy | ±3℃ |
| Coating table material | aluminum alloy |
| Wire rod application width | 300mm |
| Wire Rod Coating Thickness Range | 1-571.5 μm (Spreader thickness determined according to rod model) |
| Spreader Accuracy | ±0.001mm |
| Optional Accessories | Leakage tank, substrate fixture, trimming horizontal height support foot device, Glass plate, silicone pad and Weight (for applications with uneven thickness of Spreader substrate), application width control baffle |
| customizable function | Automatic lame plating device, UV curing device, automatic inking system, air knife drying, remote control |
Packing list
Film Applicator X1, Imported Wire Rod X1, China Wire Rod X1, Product Manual X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/46016/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
