RDS 30 #1/2 "inks scraper film thickness 68.6μm Wire diameter 0.76mm

SE
Winding process, Wire diameter 0.76mm, rod diameter 12.7mm, the main rod and steel wire are stainless steel, can film 68.6μm.
$179.00/piece
PromotionLoading...
Coupon
Model：
Certificate
Contact
Details SPEC Con VIDEO CAT OI
Similar products

RDS 30# 1/2" Applicator rod 1/2 "SPEC

RDS 30# 1/2" Applicator rod 1/2 "Details

RDS 30# 1/2" Applicator rod 1/2 "Packing list

SKU
NB004619
Production process
wire-wound
WFT
68.6μm
diameter
12.7mm
Total length
400mm
Spreader Width
300mm
Grip Width
50+50mm
material
stainless steel
Wire diameter
0.76mm
30# 1/2"
Applicator rod 1/2 "
Winding process, Wire diameter 0.76mm, rod diameter 12.7mm, the main rod and steel wire are stainless steel, can film 68.6μm.
RDS 30 #1/2 "inks scraper film thickness 68.6μm Wire diameter 0.76mm Picture

RDS 30 #1/2 "inks scraper film thickness 68.6μm Wire diameter 0.76mm Figure 1

RDS 30 #1/2 "inks scraper film thickness 68.6μm Wire diameter 0.76mm Figure 2

RDS 30 #1/2 "inks scraper film thickness 68.6μm Wire diameter 0.76mm Figure 3

RDS 30 #1/2 "inks scraper film thickness 68.6μm Wire diameter 0.76mm Figure 4

RDS 30 #1/2 "inks scraper film thickness 68.6μm Wire diameter 0.76mm Figure 5

RDS 30 #1/2 "inks scraper film thickness 68.6μm Wire diameter 0.76mm Figure 6

RDS 30 #1/2 "inks scraper film thickness 68.6μm Wire diameter 0.76mm Figure 7

RDS 30 #1/2 "inks scraper film thickness 68.6μm Wire diameter 0.76mm Figure 8

RDS 30 #1/2 "inks scraper film thickness 68.6μm Wire diameter 0.76mm Figure 9

RDS 30 #1/2 "inks scraper film thickness 68.6μm Wire diameter 0.76mm Figure 10


FAQ
QIs there any difference between this thick rod and the thin rod film?
A The wet film thickness of the same type of bar is the same, and the main reason for providing different diameters is to adapt to different operating habits and environments. For example, it is too thin to control, or some are matched with Film Applicator, which requires diameter.
QIf the topcoat is scraped on the steel plate, is this one 68 μm?
A Hello, yes.
Q70Um wet film thickness corresponds to what number of RDS scraper?
A Hello, rod 30 or 32, the film Film thickness is 68.6 microns or 73.2 microns respectively.
QDo you support customization? Such as wet film thickness and length?
A Spreader rod length and main rod diameter support customization, but wet film thickness RDS has provided dozens of specifications covering more than 200 microns, and in principle does not accept customization.
QMeet GB/T13217.1 Applicator rod
A 30 #1/2 "Applicator rod, please refer to it.
QCoating need to prevent the corrosion of acidic and alkaline substances Spreader rod, film Film thickness is 100 microns, can meet?
