Specifications
| Measuring range | 1~250mm |
| Probe frequency | 5MHz |
| Probe style | Split probe |
| Probe diameter | F10mm |
| Probe contact temperature | -10~60℃ |
| Lower limit of pipe measurement | F20 * 3mm |
| Measurement error | ±(1%H+0.1)mm |
| Display resolution | 0.1mm |
| unit system | mm |
| Calibrated | Zero calibrated |
| Sound speed range | 5920m/s |
| Display | LCD |
| Operating language | Chinese |
| Application software | without |
| Power | 2 * AAA alkalinity battery |
| Operating Time | 200h |
| Host size | 130*70*25mm |
| Weight | About 0.2kg (host) |
Packing list
Host x1, probe x1, AAA alkaline battery x1, coupling agent x1, certificate x1, manual x1, Encasement box x1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/4621/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
