Specifications
| Coating method | Rod |
| Coating speed | 1~ 300Mm/s stepless speed regulation (can be customized) |
| Substrate clamping method | fixture |
| Coating table material | Surface hardened aluminum alloy |
| Coating table size | 600*300mm |
| Effective coating Area | 400 * 300Mm (can be customized) |
| Film thickness | Controlled by bar, with high-precision imported bar |
| Bar Accuracy | ±0.001mm |
| motor | Servo motor |
| Power | 600w |
| Display | Color LCD touch screen |
| Host Power Supply | 220V 50HZ |
| Dimension | 658*438*205mm |
| Weight | 39.7kg |
| optional feature | Drawdown blade, heating, vacuum adsorption |
Packing list
Host X1, manual X1, fixture X1, imported bar X1, certificate X1
After-sales instructions
Warranty days: 730 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/46327/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
