RDS 6 #1/2 "steel wire scraping rod, rod Applicator film thickness 13.7μm Wire diameter 0.15mm

SE
Also known as the color rod, using winding process, Wire diameter 0.15mm, rod diameter 12.7mm, the main rod and steel wire are stainless steel, can film 13.7μm.
$179.00/piece
PromotionLoading...
Coupon
Model：
Certificate
Contact
Details SPEC Con VIDEO CAT OI
Similar products

RDS 6# 1/2" Applicator rod 1/2 "SPEC

RDS 6# 1/2" Applicator rod 1/2 "Details

RDS 6# 1/2" Applicator rod 1/2 "Packing list

SKU
NB004635
Production process
Wire-wound
WFT
13.7µm
diameter
12.7mm
Total length
400mm
Application width
300mm
Grip width
50+50mm
material
stainless steel
Wire diameter
0.15mm
6# 1/2"
Applicator rod 1/2 "
Also known as the color rod, using winding process, Wire diameter 0.15mm, rod diameter 12.7mm, the main rod and steel wire are stainless steel, can film 13.7μm.
RDS 6 #1/2 "steel wire scraping rod, rod Applicator film thickness 13.7μm Wire diameter 0.15mm Picture

RDS 6 #1/2 "steel wire scraping rod, rod Applicator film thickness 13.7μm Wire diameter 0.15mm Figure 1

RDS 6 #1/2 "steel wire scraping rod, rod Applicator film thickness 13.7μm Wire diameter 0.15mm Figure 2

RDS 6 #1/2 "steel wire scraping rod, rod Applicator film thickness 13.7μm Wire diameter 0.15mm Figure 3

RDS 6 #1/2 "steel wire scraping rod, rod Applicator film thickness 13.7μm Wire diameter 0.15mm Figure 4

RDS 6 #1/2 "steel wire scraping rod, rod Applicator film thickness 13.7μm Wire diameter 0.15mm Figure 5

RDS 6 #1/2 "steel wire scraping rod, rod Applicator film thickness 13.7μm Wire diameter 0.15mm Figure 6

RDS 6 #1/2 "steel wire scraping rod, rod Applicator film thickness 13.7μm Wire diameter 0.15mm Figure 7

RDS 6 #1/2 "steel wire scraping rod, rod Applicator film thickness 13.7μm Wire diameter 0.15mm Figure 8

RDS 6 #1/2 "steel wire scraping rod, rod Applicator film thickness 13.7μm Wire diameter 0.15mm Figure 9

RDS 6 #1/2 "steel wire scraping rod, rod Applicator film thickness 13.7μm Wire diameter 0.15mm Figure 10


FAQ
QDo you support customization? Such as wet film thickness and length?
A Spreader rod length and main rod diameter support customization, but wet film thickness RDS has provided dozens of specifications covering more than 200 microns, and in principle does not accept customization.
QMeet GB/T13217.1 Applicator rod
A 6 #1/2 "Applicator rod, please refer to it.
QOur company is a solar backplane, the laboratory needs to use a scraper, want to consult, want to achieve the film thickness in our mind, how to choose the rod number, no thickness of dry film can not refer to ah, before using the rds6 scraper, coated with a thickness of dry film is 4 microns, if I want to reach 6 to 8 microns, can you suggest?
A It can be roughly calculated according to dry film = wet film × solid parts. The wet film of RDS No. 6 rod is 13.7 μm, and the solid content is about 29% by calculation. If you want to make 6 μm and 8 μm dry films, you need to scrape the wet film 20.5 microns and 27.4 microns, which corresponds to RDS rod, which can be close to RDS 9 #and RDS 12. Thank you for your consultation.
