Specifications
| Coating method | Bar + air knife + air knife bracket |
| Mayer Rod Thickness Range | 1-571.5 μm (Spreader thickness according to bar model) |
| Mayer Rod Accuracy | ±0.001mm |
| Coating speed | 5-200Mm/s (< 5mm/s can be customized) |
| Coating size | 300 * 400Mm (Miscellaneous size can be customized) |
| Spreader distance control | The number can be set arbitrarily within the range of 1-400mm |
| Vacuum Area | 300 * 400Mm (can be customized) |
| vacuum aperture | Φ1.2mm |
| Vacuum hole spacing | 20*20mm |
| Vacuum pump size | 380*180*280mm |
| Substrate clamping method | Vacuum adsorption |
| Control mode | Touch screen control |
| Host Power Supply | 220V 50Hz |
| Net Weight | 65KG |
| speed control | Infinitely variable speed |
| Coating table material | aluminum alloy |
| configuration function | Air knife + air knife bracket |
| Dimension | 630*410*520mm |
| Heating Temperature range | RT+~180℃ |
| Temperature Uniformity | ±3℃ |
| Heating mode | Baseplate heating |
| Air knife gap | 0.05mm |
| Air knife Accuracy | ±0.002mm |
| Optional Accessories | Leakage tank, substrate fixture, trimming horizontal height support foot device, Glass plate, silicone pad and Weight (for applications with uneven thickness of Spreader substrate), application width control baffle |
| customizable function | Automatic lame plating device, UV curing device, automatic inking system, remote control, upper infrared heating, double extrusion Spreader |
Packing list
Film Applicator X1, External Vacuum Pump X1, Imported Wire Bar X1, Air Knife x1, Air Knife Bracket x1, Product Manual X1
After-sales instructions
Warranty days: 365 days
