Specifications
| Model | small |
| Power supply Voltage | 220V/50Hz |
| refrigeration power | 1600w |
| Refrigerant | R22 |
| freezing Capacity | 1600w |
| compressor | Type Rotor compressor; Input Power: 0.55Kw |
| refrigerant | Type: R22 |
| condenser | Type: cover pole fan; air Volume: 560m ²/h |
| evaporator | Type: stainless steel coil; tank Volume: 8L |
| Temperature range | 5~35℃ |
| Maximum pump pressure | 1bar |
| Inlet and outlet pipe diameter | DN15 |
| Rated Power | 650W |
| Shell material | Q235 spray |
| Dimension | 400*550*670mm |
| Packaging Dimensions | 470*620*850mm |
| Net Weight | 46kg |
| Instrument Gross Weight | 55kg |
| Temperature display | liquid crystal display |
| Temperature display Accuracy | 1℃ |
| Temperature control type | start stop |
| Flow rate of pump | 22L/min |
| pump head | 10m |
Packing list
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
