Specifications
| Water tank Volume | 5L |
| Temperature range | -20~100℃ |
| Temperature Fluctuation value | ±0.1℃ |
| Set Accuracy | ±0.01℃ |
| Display Accuracy | ±0.001 |
| Refrigeration power | 600W |
| cooling Capacity | 700W |
| refrigerant | R404A |
| Heating power | 1500W |
| Display temperature mode | TFT |
| setting method | touch screen |
| High temperature drop | support |
| safety protection | Low liquid level protection, high temperature protection, over temperature protection |
| Environmental temperature | 5~32℃ |
| Power supply Voltage | 200-230V |
| Circular mode | External circulation |
| Flow rate (max/rated) | 22L/min |
| Loop Interface | 10Mm pagoda Connector |
| Net Weight | 28kg |
| Gross Weight | 30kg |
| Dimensions (W * D * H) | 220*420*495mm |
| Outer box size (W * D * H) | 500*290*560mm |
Packing list
host X1, insulation pipe X2, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/46623/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
