Specifications
| Specifications | Standard type |
| lyophilized area | 0.12㎡ |
| Number of vials | Φ12mm：920；Φ16mm：480；Φ22mm：260 |
| cold trap temperature | -80℃ |
| water catch | 4Kg/batch |
| standard vacuum | ≤ 5Pa (no load) |
| Ultimate Vacuum | 2Pa |
| Overall power | 1040W |
| Power Supply | AC220V 50HZ |
| Applicable environment | Environment temperature ≤ 25 ℃ |
| Whole machine running noise | ≤55dB |
| Dimensions | 680*640*890mm |
| Packaging Dimensions | 680*640*890mm |
| Accessory Box Encasement Size | 300*300*450mm |
| Host Weight | 100kg |
| Gross Weight | 107.2kg |
Packing list
Host X1, Vacuumpump X1, power cord X1, vacuum tube clamp and gasket X1, T-type gasket X1, material tray X4, drying rack (standard type/gland type) X1, plexiglass cover X1, gland plexiglass cover X1, multi-manifold plexiglass cover X1, multi-manifold gland plexiglass cover X1, pre-freezing rack X1, eggplant bottle X1, rubber valve X1, fuse X1, vacuum grease X1, instruction manual X1, product warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/46864/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
