Specifications
| Specifications | Multi-Manifold Gland Type |
| lyophilized area | 0.08㎡ |
| Number of bottles | Φ12mm：560；Φ16mm：285；Φ22mm：165 |
| cold trap temperature | -80℃ |
| Cold trap size | Φ220*220mm |
| water catch | 4Kg/batch |
| standard vacuum | ≤ 5Pa (no load) |
| Ultimate Vacuum | 2Pa |
| Number of manifolds | 8 |
| Number of eggplant bottles | 8 |
| Overall power | 1300W (standard Vacuumpump 370W) |
| Power Supply | AC220V 25A 50HZ |
| Applicable environment | Environment temperature ≤ 30 ℃ |
| Whole machine running noise | ≦55dB |
| Dimensions | 600*558*760mm |
| Packaging Dimensions | 680*640*890mm |
| Accessory Box Encasement Size | Accessory box 1:300 * 300 * 450mm; Accessory box 2:400 * 400 * 550mm; Accessory box 3:180 * 180 * 340mm |
| Host Weight | 100kg |
| Gross Weight | 115.66kg |
Packing list
Host X1, Vacuumpump X1, power cord X1, vacuum tube clamp and gasket X1, T-type gasket X1, material tray X4, drying rack (standard type/gland type) X1, plexiglass cover X1, gland plexiglass cover X1, multi-manifold plexiglass cover X1, multi-manifold gland plexiglass cover X1, pre-freezing rack X1, eggplant bottle X1, rubber valve X1, fuse X1, vacuum grease X1, instruction manual X1, product warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
