Specifications
| container Capacity | 2000ml |
| Ultrasonic Power | 1800W can be fine-tuned |
| Ultrasonic horn | Random: φ 25 |
| Ultrasonic Frequency | 20KHZ |
| Ultrasonic Display mode | True color 7-inch touch capacitive screen high-definition display |
| Ultrasonic Control mode | MCU + TFT touch |
| Ultrasonic host material | Aluminum alloy + ABS plastic mold one-time molding |
| Power of microwave reaction system | 2100W |
| Maximum output power of microwave reaction system | 1000W |
| Microwave Frequency | 2450MH, 0-100% Power automatic continuous adjustable |
| Microwave temperature sensor | Wireless Penetrable Infrared Temperature Sensors |
| Microwave temperature Measurement Range | 0～350℃ |
| Microwave maximum temperature | 250℃ |
| Microwave temperature control Accuracy | ≤±1℃ |
| Microwave pressure Measurement Range | 0-15Mpa |
| Microwave Voltage control Accuracy | ±0.01Mpa |
| Microwaveoven cavity material | 316L industrial grade stainless steel integrated molding |
| Microwaveoven door material | Buffer floating design six-story steel structure furnace door |
| Working time | Continuous work, 0-9999s adjustable |
| Rotation speed | 0~2500rpm |
| Circulation pump model | HXS-0503 |
| Circulation pump item number | 1039019001 |
| Temperature range | -5~100℃ |
| Digital resolution | 0.1℃ |
| Inner tank Volume (length * width * depth) | 170*180*130mm |
| Flow rate of circulating pump | 8L/min |
| Filling port | Φ35mm |
| Tank Capacity | 3.5L |
| Circulation pump instrument size (depth * width * height) | 440*300*510mm |
| Microwave instrument size (L * W * H) | 500*480*550mm |
| Ultrasonic host instrument size (depth * width * height) | 427*340*168mm |
| Net Weight of circulating pump instrument | 27.5kg |
Packing list
Host X1, manual X1, tool box X1, certificate X1, warranty card X1, condensing port hose X1, feed port hose X1, four flasks X1, four bottle stoppers X1, feed port connector X2, condensing tube Glass stopper X1, serpentine condenser X1, chiller hose X2, condensing port connector X2, temperature sensor connector X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/46923/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
