Specifications
| Temperature range | Room temperature + 5 ℃ -100 ℃ |
| Temperature control Accuracy | ±0.5℃ |
| Temperature Uniformity | ±0.03℃ |
| Display resolution | 0.1℃ |
| Temperature equilibrating time | < 20Min (37 ℃ for example) |
| Control interface specification | 7 inch TFT true color touch screen |
| Spindle swirl/spin speed | 0-50Rpm continuously adjustable |
| Positive and reverse automatic switching + shaking function | Yes. |
| bottom vibrating base | without |
| Vibration intensity of bottom base | without |
| Working Timer | 0-999m59s |
| Maximum Continuous Working time | Set 0 to continuous operation |
| Hybrid tube swirling/spinning mode | Yes. |
| Linear dispersion diagram | without |
| combinatorial programming mode | Group of 5 |
| data storage | 50 sets |
| Maximum number of hybrids that can be placed | Six. |
| Hybrid tube standard specification/quantity | φ 35 × 240mm/3 pcs |
| Hybrid tube optional specifications | Phi 35 × 150mm and Phi 35 × 300mm |
| Power supply Voltage | 220VAV，50HZ |
| Power | ＜800W |
| Optional | ModBus Communication protocol |
| Instrument size | 525*370*340mm |
| Packaging Dimensions | 645*470*465mm |
Packing list
Host X1, power cord X1, manual X1, certificate X1, warranty card X1, hybrid tube X3
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/46940/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
