Specifications
| Air supply method | Bottom air duct rotary air supply |
| Temperature range | RT+10-300℃ |
| Temperature Resolution | 0.1℃ |
| Temperature Fluctuation | ±1℃ |
| Temperature Uniformity | ±2.0% |
| constitute | Interior: Mirror stainless steel plate; Exterior: Cold rolled steel plate, surface resistant painting |
| Thermal Insulation | aluminum silicate fiber |
| heater | Nickel chromium alloy heating wire |
| Rated power | 3kw |
| Exhaust Port | Inner diameter 28mm * 1, top |
| Temperature Control mode | LCD dual row PID |
| Temperature setting method | Tap the four-button setting |
| Temperature representation | Measuring temperature display: liquid crystal upper display; setting temperature display: liquid crystal lower display |
| timer | 0-9999 minutes (with Timer and waiting function) |
| Operational Features | Fixed value operation, regular operation, automatic stop, appointment start function. |
| Program Mode | optional |
| Additional features | Deviation correction, menu button lock, power outage compensation, power outage memory, overlift preventer, constant speed fan |
| Sensors | Pt100 |
| Safety Devices | Overlift preventer |
| Inner Dimensions (width * depth * height) | 600*500*750mm |
| External Dimensions (width * depth * height) | 735*625*1220mm |
| Packing size (width * depth * height) | 898*814*1347mm |
| Inner Volume | 230L |
| Shelf load bearing | 15kg |
| Shelf layer | The 17th floor. |
| Shelf spacing | 35mm |
| Power Supply | 50/60Hz AC220/13.6A |
| Net Weight/Gross Weight | 37kg/43kg |
| accessories | Shelf 2 pieces |
| Optional Accessories | Shelf, RS485 interface, printer, recorder, external communication, remote control, programmed temperature control, wireless SMS alarm, U disk data storage |
